Model Instruction
E.G.: ZA80-160A
ZA: Single stage processing pump (Over-Hang)
ZE: Single stage processing pump (Central-Support)
80: Outlet diameter is 80mm
160: Rate impeller diameter is 160mm
A(B,C....): Impeller code
Applications
Refineries, Petrochemical industry, Coal processing,
Chemical industry, Fibre processing industry, Paper & pulp industry
Sugar industry, Civil waterworks, Sea water desalination plants,
Heading & Air conditioning, Enviromental protection engineering.
Main Parts Configuration
The pump could be applied to transfer different kinds of liquid by customized wet parts, here followed our recommendation of main configuration:
Parts Name |
Clean Water |
Hot Water |
Corrosive Liquid |
Waste Water |
Pump Body |
Cast Iron |
Cast Steel/S.S304 |
S.S304/S.S316 |
Ductile Iron/Cast Steel |
Shaft |
Carbon Steel |
S.S420/42CrNi2Mo |
S.S304/S.S316 |
S.S420/42CrNi2Mo |
Shaft Sleeve |
Carbon Steel |
S.S304 |
S.S304/S.S316 |
S.S420/42CrNi2Mo |
Impeller |
Cast Iron |
Cast Steel/S.S304 |
S.S304/S.S316 |
Ductile Iron/Cast Steel |
Wearing Ring |
Cast Iron |
Cast Steel/S.S304 |
S.S304/S.S316 |
Ductile Iron/Cast Steel |
Bearing |
China Make/NSK/SKF11 |
|||
Seals |
Mechanical Seals/PTFE Packing Seals |
